AlgoLaser Alpha 22W Wood Cutting Engraving Machine Air Assist Pump Honeycomb Table Raiser Feets Support Offline Print 400*400mm
Details:
AlgoLaser Alpha 22W Wood Cutting Engraving Machine Air Assist Pump Honeycomb Table Raiser Feets Support Offline Print 400*400mm
Alpha 22W is the first real engraving machine that can reach 20000mm/min, the fastest laser engraving machine in the world
Features
Motherboard: OLM-ESP-PRO-V2.4
Spot Size: 0.05*0.1mm
Engraving Area: 400MM×400MM
Expand Engraving Area: 400MM×850MM
Available Laser Modules: 22W Laser Module (Net weight:235g)
Every 50 hours of use, please clean the lens with a medical cotton swab and alcohol."
Wave Length: 455±5nm
Focus: 50mm(From radiators to objects)
Modulation Mode: TTL
Engraving Speed: 0-20,000MM/Min
Control Softwares: Ortur APP(Laser Explorer),Web UI, LaserGRBL (free), LightBurn (Paid Software)
Input Format: jpg, svg, png, bmp, G code, CAD, AI,CDR, dwg, etc.
Available Materials of Engraving: Wood Board, Paperboard, Black Acrylic, Leather, Food, Stainless Steel, Power Coated Metal, etc.
Available Materials of Cutting: Wood Board, Paperboard, Black Acrylic, Leather, Felt Cloth, Dark Color Plastic Sheet (Melt), etc.
Input Voltage: 100V-240V (Compatible) 50/60Hz
Power Adapter Output: 24V / 4A
Operating Temp: -15℃-30℃
Safety Precautions
1. Safety Lock (Keep the Key,Professional Use Only)
2.Active Position Protection
3.Sloping Position Protection
4.Exposure Duration Detection and Limitation
5. Voltage and Current Safety Control System
6.Host Computer Watchdog
7.Emergency Stop Switch
APP function
1.Graphic Editor
2.remote Control
3.Parameter Adjustment
4.Photo upload
5.Painting
6.Material Presets
7.material library
8.barcode generator
9.Firmware upgrade
10.Engraving preview
Main Function Definition
1.WIFI Aerial
2.Power Input
3.USB Port
4.Main Power Button(Status Light)
5.TF-Card
6.Upgrade Button(for Upgrading Firmware)
7.Reset Button
8.Input and Output Ports
9.Harness Interface
10.Y-axis Motor Interface
11.YRR transfer Switch
12.YRR motor Wire PortFeatures:
22W Powerful Cutting Capability - Alpha 22W laser engraver features a powerful 22W output laser module. The laser module takes the 2nd Generation COS Optical Technology, which compresses the laser spots from a rectangle to a square(0.05*0.06mm). Allow to well engraved and to cut 15mm Paulownia Plank one pass, 12mm Basswood Plywood one pass and 10mm Black Acrylic Sheet one pass. It is ideal for those who have high requirements for cutting ability.
Groundbreaking Integrated Air Assist - You can manually adjust the speed infinitely or automatically adjust the airflow size through LightBurn, LaserGRBL or AlgoLaser App to meet different cutting and carving needs. The laser air assist quickly and efficiently reduces the surface temperature of objects during the engraving and cutting process, resulting in cleaner and clearer edges. Meanwhile, there is the airflow monitoring, lens monitoring and flame monitoring on the module.
30000mm/min Much Faster Speed - With an astonishing speed of 30000mm per minute, our AlgoLaser Alpha 22W laser engraver significantly boosts production efficiency, allowing you to complete more projects and fulfill a higher volume of orders within a limited time frame. This remarkable speed enables you to maximize your productivity and achieve greater profitability.
Triple Monitoring System - (1). Airflow monitoring: help the user to adjust the appropriate airflow size according to the engraving and cutting requirements of the work. (2). Flame monitoring: When the machine detects a flame, the status display light on the fuselage will flash red. (3). Lens dirt monitoring: when the lens dirt reaches a certain level, it will trigger an alarm to prevent lens breakage and frequent replacement.
More Functions - Power Indicator Light & Laser Indicator Light/One-step Laser Fixture/Spring-loaded Mechanical Focus/Magnetic Laser Shield (Glass)/7 Advanced Safety Features/Easy to Clean and Replace the Lens. This newly designed laser engraving and cutting machine features an ultra-powerful laser beam that can create over 500+ color choices on stainless steel by forming a thin oxide layer through chemical reaction. Make your work stand out with a colorful touch. About AlgoLaser: AlgoLaser is striving to serve people who would like to use our laser engraver for commercial use. No matter if you're exploring a new business pattern, or you're running a small custom business or you are going to take your small business up to the next level, AlgoLaser will be a valuable tool to bring your ideas from scratch to a fine finish, and generate your revenue by creating works with personal touch. Easy and fast set-up, smart operation system and thoughtful service from installation to actual operation support, with these, AlgoLaser allows you to jump right into the final model, only after a few tests and trials. Besides, its multiple security functions will help you to monitor the safety of the operation and alarm the danger. In AlgoLaser's story, we always seek progress in every customer's growth. From expanding the application boundary to supporting your customized machines, we will never stop. What you achieve is our achievement. AlgoLaser – your idea realizer. Mission: We are committed to discover the commercial use of laser machines users and develop laser application technologies for practical use, so we can offer exceptional laser solutions and services that continuously create value for users' businesses. Vision: Become the evangelist and leader in the commercial laser equipment industry. The 2nd COS Optical Technology: Adopting the advanced second-generation COS technology, the polarized beam combination improves the performance of the laser beam by 40%. Compared to regular 20W lasermodules, COS technology compresses the laser spots from arectangle to a square having a near 1:l ratio on both low (3%) and high power (100%). Support Mobile App Operation: You can directly use the mobile phone to shoot or use the photos in the mobile phone album to create, or use the mobile app to operate the content engraving in the SD card. Indicators:There is a Laser indicator light, Power indicator light, Air indicator light, Lens indicator light and Flame indicator light. 1) Laser indicator light: check if the laser module can emit beam. If it can, the light will be blue. 2) Power indicator light: check if the machine was powered on. 3) Air indicator light: monitoring the airflow. If there is no airflow, the light will be red. If the airflow is weak, the light will be yellow. If the airflow is 100%, the light will be green. 4) Lens indicator light: check if the lens needs to be cleaned. 5) Flame indicator light: flame detection. Spring-loaded Mechanical Focus:Innovative patented design for instant rebound, ensuring pristine engraving results. One-step Laser Fixture:A revolutionary self-developed fixture, providing enhanced stability compared to single-point fixtures. Magnetic Laser Shield:Easy to take out the laser shield. And the material is glass, which is good to use and protect your eyes. 7 Advanced Safety Features:Give you a safety engraving environment. Time is money in the engraving business, and with engraving speeds of up to 30000 mm/min, the Alpha22W is designed to save both. For example, a 210*280mm grayscale image that takes other machines 270 minutes to complete can be done by Alpha 22W in just 36 minutes.
AlgoLaser Alpha 22W Wood Cutting Engraving Machine Air Assist Pump Honeycomb Table Raiser Feets Support Offline Print 400*400mm
Alpha 22W is the first real engraving machine that can reach 20000mm/min, the fastest laser engraving machine in the world
Features
Motherboard: OLM-ESP-PRO-V2.4
Spot Size: 0.05*0.1mm
Engraving Area: 400MM×400MM
Expand Engraving Area: 400MM×850MM
Available Laser Modules: 22W Laser Module (Net weight:235g)
Every 50 hours of use, please clean the lens with a medical cotton swab and alcohol."
Wave Length: 455±5nm
Focus: 50mm(From radiators to objects)
Modulation Mode: TTL
Engraving Speed: 0-20,000MM/Min
Control Softwares: Ortur APP(Laser Explorer),Web UI, LaserGRBL (free), LightBurn (Paid Software)
Input Format: jpg, svg, png, bmp, G code, CAD, AI,CDR, dwg, etc.
Available Materials of Engraving: Wood Board, Paperboard, Black Acrylic, Leather, Food, Stainless Steel, Power Coated Metal, etc.
Available Materials of Cutting: Wood Board, Paperboard, Black Acrylic, Leather, Felt Cloth, Dark Color Plastic Sheet (Melt), etc.
Input Voltage: 100V-240V (Compatible) 50/60Hz
Power Adapter Output: 24V / 4A
Operating Temp: -15℃-30℃
Safety Precautions
1. Safety Lock (Keep the Key,Professional Use Only)
2.Active Position Protection
3.Sloping Position Protection
4.Exposure Duration Detection and Limitation
5. Voltage and Current Safety Control System
6.Host Computer Watchdog
7.Emergency Stop Switch
APP function
1.Graphic Editor
2.remote Control
3.Parameter Adjustment
4.Photo upload
5.Painting
6.Material Presets
7.material library
8.barcode generator
9.Firmware upgrade
10.Engraving preview
Main Function Definition
1.WIFI Aerial
2.Power Input
3.USB Port
4.Main Power Button(Status Light)
5.TF-Card
6.Upgrade Button(for Upgrading Firmware)
7.Reset Button
8.Input and Output Ports
9.Harness Interface
10.Y-axis Motor Interface
11.YRR transfer Switch
12.YRR motor Wire PortFeatures:
22W Powerful Cutting Capability - Alpha 22W laser engraver features a powerful 22W output laser module. The laser module takes the 2nd Generation COS Optical Technology, which compresses the laser spots from a rectangle to a square(0.05*0.06mm). Allow to well engraved and to cut 15mm Paulownia Plank one pass, 12mm Basswood Plywood one pass and 10mm Black Acrylic Sheet one pass. It is ideal for those who have high requirements for cutting ability.
Groundbreaking Integrated Air Assist - You can manually adjust the speed infinitely or automatically adjust the airflow size through LightBurn, LaserGRBL or AlgoLaser App to meet different cutting and carving needs. The laser air assist quickly and efficiently reduces the surface temperature of objects during the engraving and cutting process, resulting in cleaner and clearer edges. Meanwhile, there is the airflow monitoring, lens monitoring and flame monitoring on the module.
30000mm/min Much Faster Speed - With an astonishing speed of 30000mm per minute, our AlgoLaser Alpha 22W laser engraver significantly boosts production efficiency, allowing you to complete more projects and fulfill a higher volume of orders within a limited time frame. This remarkable speed enables you to maximize your productivity and achieve greater profitability.
Triple Monitoring System - (1). Airflow monitoring: help the user to adjust the appropriate airflow size according to the engraving and cutting requirements of the work. (2). Flame monitoring: When the machine detects a flame, the status display light on the fuselage will flash red. (3). Lens dirt monitoring: when the lens dirt reaches a certain level, it will trigger an alarm to prevent lens breakage and frequent replacement.
More Functions - Power Indicator Light & Laser Indicator Light/One-step Laser Fixture/Spring-loaded Mechanical Focus/Magnetic Laser Shield (Glass)/7 Advanced Safety Features/Easy to Clean and Replace the Lens. This newly designed laser engraving and cutting machine features an ultra-powerful laser beam that can create over 500+ color choices on stainless steel by forming a thin oxide layer through chemical reaction. Make your work stand out with a colorful touch. About AlgoLaser: AlgoLaser is striving to serve people who would like to use our laser engraver for commercial use. No matter if you're exploring a new business pattern, or you're running a small custom business or you are going to take your small business up to the next level, AlgoLaser will be a valuable tool to bring your ideas from scratch to a fine finish, and generate your revenue by creating works with personal touch. Easy and fast set-up, smart operation system and thoughtful service from installation to actual operation support, with these, AlgoLaser allows you to jump right into the final model, only after a few tests and trials. Besides, its multiple security functions will help you to monitor the safety of the operation and alarm the danger. In AlgoLaser's story, we always seek progress in every customer's growth. From expanding the application boundary to supporting your customized machines, we will never stop. What you achieve is our achievement. AlgoLaser – your idea realizer. Mission: We are committed to discover the commercial use of laser machines users and develop laser application technologies for practical use, so we can offer exceptional laser solutions and services that continuously create value for users' businesses. Vision: Become the evangelist and leader in the commercial laser equipment industry. The 2nd COS Optical Technology: Adopting the advanced second-generation COS technology, the polarized beam combination improves the performance of the laser beam by 40%. Compared to regular 20W lasermodules, COS technology compresses the laser spots from arectangle to a square having a near 1:l ratio on both low (3%) and high power (100%). Support Mobile App Operation: You can directly use the mobile phone to shoot or use the photos in the mobile phone album to create, or use the mobile app to operate the content engraving in the SD card. Indicators:There is a Laser indicator light, Power indicator light, Air indicator light, Lens indicator light and Flame indicator light. 1) Laser indicator light: check if the laser module can emit beam. If it can, the light will be blue. 2) Power indicator light: check if the machine was powered on. 3) Air indicator light: monitoring the airflow. If there is no airflow, the light will be red. If the airflow is weak, the light will be yellow. If the airflow is 100%, the light will be green. 4) Lens indicator light: check if the lens needs to be cleaned. 5) Flame indicator light: flame detection. Spring-loaded Mechanical Focus:Innovative patented design for instant rebound, ensuring pristine engraving results. One-step Laser Fixture:A revolutionary self-developed fixture, providing enhanced stability compared to single-point fixtures. Magnetic Laser Shield:Easy to take out the laser shield. And the material is glass, which is good to use and protect your eyes. 7 Advanced Safety Features:Give you a safety engraving environment. Time is money in the engraving business, and with engraving speeds of up to 30000 mm/min, the Alpha22W is designed to save both. For example, a 210*280mm grayscale image that takes other machines 270 minutes to complete can be done by Alpha 22W in just 36 minutes.
