ORTUR Laser Engraver DIY KIT Y-axis Laser Rotary Roller Desktop Engraving Cutting Cutter Machine Metal Woodworking 400x400mm

Details:






ORTUR Laser Engraver DIY KIT Y-axis Laser Rotary Roller Desktop Engraving Cutting Cutter Machine Metal Woodworking 400x400mm


Features:Motherboard:ALGOLASER_DIY_KIT_V1.2Engraving area: 400*400mmWith Expand kits Engraving area :400*800mm(need to order separately)Control Software:LaserGRBL (free), LightBurn (Paid Software), Wifi APPSafety Precautions:Machine Offset Detection and ProtectionMachine Tilt Detection and ProtectionUSB Connection Detection and ProtectionBeam detection and protectionCurrent and Voltage Detection and ProtectionEmergency Stop SwitchKey LockFrame Materials:Aluminum ProfileMotors:NEMA 42 Stepper MotorsMechanical Precision:Y:12.5um, X:12.5umPixel Accuracy:Adjustable (Default: 300 pixels per inch, about 0.81um Pixel Accuracy)Engraving Area:X400mm*Y400mmElectric Power:72WLuminous Power:5W/10WWave Length:445±5nmControl Mode:PWMPower Rate:S0-S1,000Engraving Speed:0-12,000MM/MinBaud Rate:115200 - 921600 (Default: 115200)Computer OS:Win XP, Win 7, Win 8, Win 10 (LaserGRBL)Mac and Linux (LightBurn)Control Softwares:LaserGRBL (free), LightBurn (not free), Wifi AppInput Format:BMP, JPG, PNG, NC, DXF, SVG, etc.Available Materials of Engraving:Wood, Paperboard, Black Acrylic, Leather, Some Plastic(opaque), Power Coated Metal, etc.Available Materials of Cutting:Paper Board, KT Board, Felt Cloth, Leather, Thin Plywood, Thin Black Acrylic, etc.Input Voltage:110V-240V (Compatible)Power Adapter Output:24V / 3AOperating Temp.:-20℃-50℃


1.The Y rotary is used for laser engraving cylindrical objects of varying diameters.
2. AlgoLaser laser rotary roller is compatible with different models of engraving machines.
3. This product is an accessory part of the AlgoLaser
range of laser engraving machines and not a standalone device. To maintain maximum efficiency, it needs to work in conjunction with an
AlgoLaser laser engraving machine.


UPGRADE 1.8 FIRMWARE:
AlgoLaser Series Firmware has been optimized for faster speed engraving. Taking advantage of the faster ESP32 McU.1. The main frequency is as high as 240MHZ.2. The working efficiency is high, and the machine moves fast.3. With current and voltage detection functions, better protection of the machine.4. Active power-off function, which can actively disconnect the power supply in the case of abnormal power supply.5. Support AlgoLaser series digital Laser module, it could adjust the laser heat dissipation time after the engraving is completed according to the use of the digital laser module.6. The use of efficient real-time operating system Freertos system is more stable and more efficient.



ALGOLASER ADVANTAGES:

1. AlgoLaser upgraded firmware, smarter, faster, higher precision and easier to use, support both computer and Cellphones to use.2. It could pre-process 32 instructions, support baud rate as high as 921600, max. 12000mm/min.3. Allows you to enjoy more intelligent and safer laser engraving machine engraving with emergency stop buttons and safety lock functions.

SAFETY PROTECTIONS PROVIDES YOU WITH A SAFE ENGRAVING ENVIRONMENT.
